5 MP Explosion Proof Network Bullet Camera

Send Inquiry

Request To Call Back

5 MP Explosion Proof Network Bullet Camera

Name: 5 MP Explosion Proof Network Bullet Camera
Brand: QANDS SERVICES AND TECHNOLOGIES LLP
Price: 100000.0 INR
Availability: InStock

Price 100000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

5 MP Explosion Proof Network Bullet Camera Specification

Lens
5.3 159 mm, F1.6 F4.3, P-Iris, 30X Optical Zoom

Sensor
CCD

Technology
NetWork

View Angle
Approx. 59.8 2.3

Media Type
Flash Memory

Product Type
IP Camera

Features
WDR, 30X Optical Zoom, H.265, IP66/IP68/IP69, 120 dB WDR, 3D DNR, EIS, Built-in Heater, Wiper & Washer

Sensor Size
7.18*5.32mm

Aperture
F1.6 F4.3

ISO
Not Applicable

IR Distance
Up to 300 m

Battery
Not Applicable

Flash Point
Not Applicable

Feature
Weatherproof

WiFi
Yes

Color
Silver

Body Material
AISI 316L Stainless Steel

Pixels
5 Megapixel (MP )

Screen Size
Not Applicable Meter (m)

Zoom Option
30X Optical Zoom

Memory Card Type
Micro SD/SDHC/SDXC

Video Capture
Yes

Video Capture Resolution
5 MP (2592 1944)

5 MP Explosion Proof Network Bullet Camera Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
500 Units Per Month

Delivery Time
7 Days

About 5 MP Explosion Proof Network Bullet Camera

Product Description

Enhance the safety and security of hazardous industrial environments with the Honeywell HCS1WB5XD30WXXX 5MP Explosion Proof IR Bullet Network Camera. Designed for continuous surveillance in explosive atmospheres, this rugged camera combines 5MP high-resolution imaging, 30X optical zoom, and True Wide Dynamic Range (120 dB WDR) to deliver crystal-clear video even in challenging lighting conditions.
Built with a durable AISI 316L stainless steel explosion-proof housing, the camera is certified to ATEX and IECEx standards, making it suitable for Gas Zone 1 & 2 and Dust Zone 21 & 22 hazardous areas. With IP66, IP68, and IP69 protection ratings, it withstands harsh weather, water, dust, and corrosive industrial environments.
The camera supports H.265, H.264, and MJPEG compression, ONVIF Profile S/G/T compatibility, intelligent video analytics such as intrusion detection, loitering detection, motion detection, and people counting, making it an ideal surveillance solution for oil & gas, offshore, marine, petrochemical, chemical, power, and heavy industrial facilities.

Key Features

Genuine Honeywell HCS1WB5XD30WXXX Explosion Proof Bullet Camera

5 MP high-resolution progressive scan image sensor

Powerful 30X Optical Zoom with P-Iris lens

True Day/Night imaging with 120 dB WDR

Excellent low-light performance (minimum illumination 0.005 Lux)

Rugged AISI 316L Stainless Steel explosion-proof housing

Certified for ATEX & IECEx hazardous locations

Suitable for Gas Zone 1 & 2 and Dust Zone 21 & 22

IP66, IP68 & IP69 weatherproof protection

Built-in heater for reliable operation in extreme temperatures

Integrated wiper and washer control system

Supports H.265, H.264 & MJPEG video compression

ONVIF Profile S, G & T compliant

Supports intelligent analytics including:

Motion Detection

Intrusion Detection

Loitering Detection

People Counting

Tamper Detection

Smart Motion Detection (SMD)

Supports Electronic Image Stabilization (EIS)

NDAA Section 889 compliant

Cyber security features with signed certificates and AES256 encryption

Flexible power options: 100240 VAC, 24 VAC, 24 VDC, or PoE++

Engineered for Extreme Safety

Made with AISI 316L stainless steel, this explosion-proof camera is designed for hazardous locations where traditional surveillance equipment isn't suitable. Its rugged structure and built-in heater allow it to withstand extreme weather, temperature fluctuations, and industrial environments, ensuring critical infrastructure is always monitored safely.

Advanced Imaging Capabilities

Featuring a 5-megapixel sensor, 30X optical zoom, and P-Iris control, the camera delivers outstanding image clarity over variable distances. Technologies like H.265 video compression, 120 dB wide dynamic range, and 3D digital noise reduction guarantee clear footage, even in challenging lighting or high-contrast scenes.

Installation Flexibility and Performance

With support for network connectivity, micro SD storage, and a weatherproof IP66/IP68/IP69 rating, this camera adapts to diverse security applications. Its built-in wiper, washer, and heater ensure optimal lens clarity, while infrared night vision up to 300 meters extends surveillance capability around the clock.

FAQ's of 5 MP Explosion Proof Network Bullet Camera:

Q: How does the explosion-proof feature of the camera ensure safety in hazardous environments?

A: The explosion-proof design, crafted from AISI 316L stainless steel, prevents internal sparks or heat from igniting potentially flammable gases or particles. This makes it safe for use in industrial areas such as oil refineries, chemical plants, and other high-risk zones.

Q: What image quality can I expect from the 5 MP camera, and how does the 30X optical zoom enhance usage?

A: The 5 MP resolution (2592 1944 pixels) ensures high-definition video, capturing fine details across a wide scene. The 30X optical zoom allows close-up monitoring of distant objects without compromising clarity, making it ideal for both wide area and focused surveillance.

Q: Where is this camera typically installed, given its robust and weatherproof features?

A: This model is best suited for hazardous outdoor or industrial settings such as petrochemical plants, mining sites, ports, and critical infrastructure locations. Its IP66/IP68/IP69 rating ensures dependable operation regardless of exposure to dust, water, or harsh weather.

Q: When is the built-in heater, wiper, and washer system most beneficial?

A: The built-in heater, wiper, and washer maintain clear lens visibility during adverse weather-such as rain, snow, or dust storms-ensuring consistent surveillance performance during extreme conditions or temperature drops.

Q: What are the storage options and network features for this camera?

A: The camera supports micro SD/SDHC/SDXC cards for onboard video storage, and its network technology allows for seamless remote access, monitoring, and integration with existing security systems for convenient management.

Q: How does the camera maintain video quality in varying lighting conditions?

A: Equipped with 120 dB wide dynamic range, 3D digital noise reduction (DNR), and electronic image stabilization (EIS), the camera adapts to changes in lighting and movement, delivering sharp, balanced images during both day and night.
