Digital Torque Tester

Name: Digital Torque Tester
Brand: QANDS SERVICES AND TECHNOLOGIES LLP
Price: 185000.0 INR
Availability: InStock

Price 185000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Digital Torque Tester Specification

Usage
Bottle Cap Torque Testing

Product Type
Digital Torque Tester

Interface Type
USB

Port Size
USB

Classification
Digital Bottle Cap Torque Tester

Operate Method
Manual

Accuracy
1% %

Capacity
N/A Pcs/min

Dimension (L*W*H)
19.5 11.5 5.75 Inch (in)

Gas Pressure
N/A Bar

Power
USB Power Adapter Ampere (amp)

Features
Digital Display, Peak Hold, USB Powered, High Accuracy, Rechargeable Battery

Humidity
N/A

Power Supply
Electric

Weight
5.44 kg Kilograms (kg)

Test Range
0 100 Inch-lbs

Mounting Type
Bench Top

Hardness
N/A

Temperature
Ambient Celsius (oC)

Resolution
0.1 Inch-lb

Voltage
220-240 Volt (v)

Application
Bottle Cap Torque Testing, Quality Control

Automation Grade
Manual

Number of Specimens
1 Bottle Cap

Measuring Range
0 100 Kelvin (K)

Equipment Type
Digital Bottle Cap Torque Tester

Material
Metal

Operating Voltage
USB Power Adapter Volt (V)

Max Height
N/A

Response Time
Peak Hold Approx. 20 Seconds

Display Type
Digital

Frequency
50/60 Hz Hertz (HZ)

Specimen Size
Bottle Caps Millimeter (mm)

Color
Silver

Machine Weight
5.44 kg Kilograms (kg)

Test Speed
Manual

Test Width
N/A Millimeter (mm)

Test Stroke
Other

Control Mode
Manual

Digital Torque Tester Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
1000 Units Per Month

Delivery Time
7 Days

Digital Torque Tester About

Product Description

The Digital Bottle Cap Torque Tester is designed to deliver accurate and reliable torque measurements for bottle cap application and removal testing. Featuring a high-precision digital torque meter, this tester provides refined readings with excellent repeatability, making it an ideal solution for quality control laboratories, packaging facilities, beverage manufacturers, pharmaceutical companies, and food processing industries.

With a testing range of 0100 inch-lbs, the instrument accurately measures both cap tightening and removal torque while displaying results in either inch-pounds or Newton-meters. The digital display captures and holds the peak reading for approximately 20 seconds, allowing operators to record measurements with confidence.

Powered by a USB adapter with an internal rechargeable lithium battery, the Digital Torque Tester offers reliable performance and user-friendly operation. It can also be upgraded to a Computer Interface Torque Tester, providing additional flexibility for advanced testing and data management requirements.

Key Features

High-Precision Digital Bottle Cap Torque Tester
Suitable for Both Cap Application & Removal Torque Testing
Measuring Range: 0100 Inch-lbs
Displays Readings in Inch-lbs and Newton-meters
Resolution up to 0.1 Inch-lb for Precise Measurements
Accuracy of 1% of Full Scale or Reading
Peak Hold Function for Easy Data Recording
USB Powered with Internal Rechargeable Lithium Battery
Upgradeable to Computer Interface Torque Tester
Optional Teflon-Coated Model for Chemical & Laboratory Environments
Durable Construction for Continuous Quality Control Testing
Ideal for Beverage, Pharmaceutical, Food Processing, Cosmetic & Packaging Industries

High-Precision Torque Measurement

This digital torque tester provides a resolution of 0.1 inch-lb, enabling highly precise measurements for bottle caps in various industries. Its peak hold feature captures the maximum torque value for up to 20 seconds, allowing for thorough data review. Designed with accuracy in mind, the tester ensures your quality control processes meet rigorous standards.

User-Friendly Design with Reliable Power

Operating on manual control, the device is intuitive to use and requires minimal setup. It's powered by a USB adapter (220-240 Volt), offering flexibility and portability for different workstations. The robust metal build and compact bench-top design make it suitable for continuous quality assessments in labs or production settings.

Versatile Application Across Industries

Whether testing in the food, pharmaceutical, beverage, or packaging fields, this torque tester is engineered for comprehensive cap testing requirements. The digital display clearly shows measurements, while the USB interface allows data logging and export, supporting efficient documentation and compliance with industry standards.

FAQ's of Digital Torque Tester:

Q: How do I operate the Digital Torque Tester for bottle cap testing?

A: To operate the tester, securely place the bottle cap specimen in the holding mechanism and use the manual control to apply torque. The digital display will show real-time torque readings; the peak hold feature will store the highest value for up to 20 seconds for convenient data recording.

Q: What types of caps and applications are suited for this torque tester?

A: This device is specifically designed for testing bottle cap torque in applications such as packaging, beverage, pharmaceutical, and food processing. It works for both application and removal torque testing, ideal for routine quality control on various bottle cap sizes commonly found in these industries.

Q: When should I use the peak hold function?

A: The peak hold function is best used during critical torque measurement moments-such as when you need to record the highest torque applied to a cap during application or removal. The device will retain the peak value for approximately 20 seconds, making it easier to log results accurately.

Q: Where can I install the Digital Torque Tester?

A: Designed as a bench-top instrument, the torque tester can be installed on any stable lab or production worktable. Its compact size and USB-powered operation make it adaptable to various working environments, whether in a laboratory, production line, or quality control area.

Q: What is the process for connecting the device and exporting data?

A: Simply connect the tester to a power source via the included USB adapter. The USB interface also facilitates easy data transfer to computers or external systems, helping you manage and archive test results efficiently for traceability and reporting.

Q: What are the benefits of its digital display and manual operation?

A: The digital display offers clear, accurate readings, reducing the risk of human error. Manual operation gives users controlled, hands-on testing-important for customizing test speeds and ensuring every cap is evaluated precisely according to your requirements.

Q: Is the Digital Torque Tester portable and suitable for frequent use?

A: Yes, weighing 5.44 kg and equipped with a rechargeable battery and USB power, the tester is both portable and reliable for frequent use. Its durable metal construction ensures longevity even with routine handling in busy industrial and laboratory settings.
