Explosion Proof Panel PC

Name: Explosion Proof Panel PC
Brand: QANDS SERVICES AND TECHNOLOGIES LLP
Price: 400000.0 INR
Availability: InStock

Price 400000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Explosion Proof Panel PC Specification

Processor Main Frequency
Configurable Hertz (HZ)

Weight
12 Kilograms (kg)

Cache
Configurable

Camera
Other

Screen Resolution
1920 1080 (Full HD)

Processor Type
Industrial Embedded Processor

Screen Size
24 Inch (in)

Bluetooth
Yes

Monitor
LED

CPU
Industrial Panel PC CPU

Chipset
Intel Platform

Graphics
OTher

Memory
Configurable RAM Gigabyte (GB)

Memory Speed
Configurable

Memory Upgradable upto
yes Megabyte (MB)

HDD
SDD byte (B)

LAN
2 10/100Base-TX Ethernet LAN (CAT7, up to 100 m)

Mouse
Mechanical Mouse

Keyboard
Other

OS
Windows / Linux

Connectivity Options
2 10/100Base-TX Ethernet

Warranty Period
1 Year

Explosion Proof Panel PC Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
1000 Units Per Month

Delivery Time
7 Days

About Explosion Proof Panel PC

Product Description

The R. STAHL Panel PC Series 400 MANTA PM MT-477-TX is a 24-inch Full HD explosion-proof HMI Panel PC designed for hazardous areas classified as Zone 2 and Zone 22. Featuring ATEX, IECEx, IP66 protection, optional touchscreen, and dual Ethernet connectivity, it provides reliable industrial monitoring and control for oil & gas, petrochemical, chemical, pharmaceutical, marine, and power generation applications.

Key Features

R. STAHL Panel PC Series 400 (MANTA Platform)

Model PM MT-477-TX

24-inch Full HD (1920 1080) Widescreen Display

Explosion-Protected for Zone 2 & Zone 22

ATEX, IECEx, CCC & CNEx Certified

IP66 Dust & Water Protection

Panel Mount Design for Industrial HMI Applications

Operates on 100240 V AC, 50/60 Hz

Optional Resistive Glass or Foil Touchscreen

Dual 10/100Base-TX Ethernet Connectivity

CAT7 Data Transmission up to 100 m

Configurable Memory & SSD Options

Can Be Installed Without Additional Enclosure

Ideal for Industrial Automation & Process Monitoring

Suitable for Oil & Gas, Petrochemical, Chemical, Marine, Pharmaceutical & Power Industries

Built for Safety and Performance

Engineered to withstand explosive atmospheres, this panel PC protects both personnel and equipment in critical settings. Its explosion-proof design meets stringent safety standards, ensuring uninterrupted operation in hazardous locations such as oil & gas or chemical plants.

Versatile Connectivity and Display

Equipped with two LAN ports supporting CAT7 cabling and a 24-inch Full HD LED touchscreen, this panel PC enables seamless integration with your existing networks. The wall-mountable form factor and industrial-grade components suit demanding industrial environments.

Customizable and Reliable

With configurable processor frequency, memory, and cache options, you can tailor the PC to specific application needs. Solid-state drive storage promises durability, and the upgradable RAM makes it adaptable for future requirements. Supported by a one-year warranty, reliability is assured.

FAQ's of Explosion Proof Panel PC:

Q: How does the explosion-proof feature of the panel PC enhance workplace safety?

A: The explosion-proof design ensures the device can safely operate in environments with flammable gases or dust, preventing any sparks or heat from igniting hazardous materials and thereby protecting personnel and equipment.

Q: What is the process for mounting this panel PC in an industrial setting?

A: The panel PC is designed for wall mounting. Installation involves securely attaching the device to the wall using the provided brackets and connecting the AC power supply, ensuring it is positioned for optimal use within your facility.

Q: Where is this explosion-proof panel PC commonly used?

A: This panel PC is ideal for hazardous industrial sites such as oil refineries, chemical plants, and facilities where flammable or explosive atmospheres may be present.

Q: What are the benefits of the dual 10/100Base-TX Ethernet LAN ports?

A: Dual Ethernet LAN ports offer robust network connectivity, redundancy for critical operations, and the capacity to connect multiple networks or devices efficiently, supporting seamless data communication.

Q: When can the memory of the panel PC be upgraded and to what extent?

A: Memory can be upgraded as your application requirements evolve. Consult the supplier to determine the compatible memory limits and configuration options before or after initial deployment.
