Flamproof Cable Gland

Name: Flamproof Cable Gland
Brand: QANDS SERVICES AND TECHNOLOGIES LLP
Price: 200.0 INR
Availability: InStock

Price 200.0 INR/ Piece

Get a Price/Quote

MOQ : 50 Pieces

Flamproof Cable Gland Specification

Impedance
Not Applicable Volt (v)

Diameter
16 mm 101.4 Millimeter (mm)

Locking Type
Threaded with Armour Clamping & Barrier Seal

Tensile Strength
High Mechanical Strength Kilopascals (KPa)

Armored Material
SWA, AWA, STA, Wire Braid, PWA, EMC Cable Armour

Conductor Shape
Round

Conductor Type
Other

Rated Temperature
-60 C to +85 C Celsius (oC)

Core Number
Suitable for Single & Multi-Core Cables

Core Material
Copper / Aluminium Cable Compatible

Insulation
CMP SOLO LSF Halogen-Free Thermoset Elastomer

Features
Explosion Proof, Barrier Type, Flameproof, IP66/IP67/IP68, Corrosion Resistant, Metal-to-Metal Armour Clamping

Operating Temperature
-60 C to +85 C Celsius (oC)

Usage & Applications
Oil & Gas, Offshore, Marine, Petrochemical, Chemical Plants, Mining & Power Industries

Weight
4.31 Kilograms (kg)

Dielectiric Strength
As per IEC 62444 Standard Kilopascals (KPa)

Number of Conductor
Multi-Core

Install Type
Panel Mount

Cable Type
Armoured Cable

Product Type
Flameproof Barrier Cable Gland

Power Rating
Not Applicable

Length
62 114 Millimeter (mm)

Insulation Material
Brass

Application
Industrial, Construction

Conductor Material
Aluminum

Jacket Material
Other

Storage Temperature
-60 C to +85 C Celsius (oC)

Connector Color
Metallic Silver

Rated Voltage
Not Applicable Volt (V)

Shield Material
Suitable for Screened

Jacket Color
Other

Dimension (L*W*H)
62 34 34 Millimeter (mm)

Display Type
Not Applicable

Warranty
1 Year

Phase
Not Applicable

Frequency
Not applicable Hertz (HZ)

Conductor
Suitable for Armoured Copper & Aluminium Cables

Rated Current
Not Applicable Volt (v)

Color
Metallic Silver

Material
Brass, Nickel Plated Brass, SS316 Stainless Steel, Aluminium

Size
M20 to M100

Flamproof Cable Gland Trade Information

Minimum Order Quantity
50 Pieces

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

Flamproof Cable Gland About

Description

The CMP PX2K Explosion Proof Barrier Cable Gland is a globally certified flameproof cable gland designed for all types of armoured cables. Featuring a compound barrier seal, IP66/IP67/IP68 protection, and certifications including IECEx, ATEX, UKEX, UL, CSA, and PESO, it provides secure cable termination for hazardous industrial environments.

Key Features

Designed for all types of armoured cables, including SWA, AWA, STA, Wire Braid, PWA, and EMC cables.
Compound barrier flameproof seal for enhanced hazardous area protection.
Metal-to-metal armour clamping for secure cable termination.
Controlled outer load retention seal with integral protected deluge seal.
Available in Brass, Nickel Plated Brass, Stainless Steel, and Aluminium construction.
IP66, IP67 & IP68 ingress protection for dust and water resistance.
Wide operating temperature range from -60C to +85C.
Certified to IECEx, ATEX, UKEX, UL, CSA, PESO (India), EAC, and other global standards.
Suitable for Zone 1, Zone 2, Zone 21 & Zone 22 hazardous locations.
Available in multiple thread sizes from M20 to M100 with Metric and NPT options.
Excellent corrosion resistance for offshore, marine, and industrial environments.
Ideal for Oil & Gas, Petrochemical, Chemical, Marine, Mining, and Power industries.

Engineered for Extreme Environments

Built for applications where safety and reliability are paramount, the Flamproof Cable Gland thrives in the harsh conditions of petrochemical plants, offshore rigs, mining sites, and power installations. Its high mechanical strength and corrosion resistance ensure long-term protection for cable entries against hazardous elements.

Reliable Safety Features

With certified explosion and flameproof designs, along with IP66/67/68 ingress protection, these glands deliver a secure seal against dust, water, and flammable substances. Their barrier-type construction and metal-to-metal armour clamping are key for installations where operational safety is non-negotiable.

Versatile Cable Compatibility

Compatible with round, single, and multi-core cables, these glands fit wide diameter ranges (16 mm to 101.4 mm) and various armoured types, such as SWA, AWA, STA, wire braid, and PWA. They support both copper and aluminium conductors, making them an adaptable choice for multiple industries and cable specifications.

FAQ's of Flamproof Cable Gland:

Q: How is the Flamproof Cable Gland installed for optimal safety?

A: The gland is panel-mounted and secured using a threaded system with metal-to-metal armour clamping and a barrier seal. Proper installation ensures a tight, flameproof, and explosion-resistant connection that maintains enclosure integrity even under harsh conditions.

Q: What types of cables are compatible with this cable gland?

A: This gland suits both single and multi-core armoured cables made from copper or aluminium. It supports various armour types like SWA, AWA, STA, wire braid, PWA, and even EMC cable armour, accommodating diameters from 16 mm to 101.4 mm.

Q: Where can Flamproof Cable Glands be used?

A: They are ideally used in environments with explosive and corrosive risks-such as oil & gas refineries, offshore rigs, marine settings, petrochemical plants, power stations, mines, and chemical plants.

Q: What benefits does this product offer in industrial applications?

A: The gland's explosion- and flameproof design, combined with IP66/67/68 ratings and high mechanical strength, provides enhanced safety, durability, and protection against dust, water, and corrosive materials, significantly reducing operational risk.

Q: When should Flamproof Cable Glands be selected over standard cable glands?

A: They should be chosen when installation takes place in areas classified as hazardous, or where high resistance to explosion, fire, and ingress of water or dust is required to maintain safety standards and compliance.

Q: How does this cable gland maintain dielectric strength and insulation?

A: It utilizes CMP SOLO LSF halogen-free thermoset elastomer insulation, meeting IEC 62444 standards for dielectric strength and safety in electrical applications.
