Wine Cork Pull Tester

Price 180000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Piece

Wine Cork Pull Tester Specification

Display Type
Digital LCD with EL Backlight

Classification
Digital Force Testing Equipment

Color
Silver

Equipment Type
Wine Cork Pull Tester

Operating Voltage
100 240 V AC Volt (V)

Temperature
Ambient Laboratory Temperature Celsius (oC)

Mounting Type
Bench Top

Gas Pressure
Not Applicable N/m2

Operate Method
Manual Lever Operation

Capacity
50 kgf Kg

Test Range
110 lbf

Voltage
100 240 V Volt (v)

Automation Grade
Manual

Usage
Industrial / Laboratory

Resolution
0.1 N

Interface Type
RS-232C, Digimatic & Analog Output

Specimen Size
Standard Wine Bottles Meter (m)

Application
Wine Bottle Quality Control, Cork Pull Force Testing, Wineries, Cork Manufacturers, Packaging Laboratories

Response Time
Instant Seconds

Measuring Range
0 490 N Newton

Frequency
50/60 Hz Hertz (HZ)

Features
Peak Hold, Overload Protection, Data Memory (1000 Readings), High/Low Set Points, USB/RS-232 Data Output, Backlit Display

Accuracy
0.2% Full Scale mg

Hardness
Cork Pull Strength Testing

Material
MS

Max Height
Standard Wine Bottle

Power Supply
Ni-MH Rechargeable Battery or AC Adapter

Number of Specimens
1

Power
AC Adapter / Rechargeable Battery Ampere (amp)

Product Type
Wine Cork Pull Tester

Humidity
Not Applicable

Weight
12 Kilograms (kg)

Dimension (L*W*H)
45 30 70 Centimeter (cm)

Port Size
Not Applicable

Machine Weight
12 Kilograms (kg)

Test Speed
Manual Lever Operation

Test Width
30 Centimeter (cm)

Test Stroke
60 mm

Control Mode
Manual

Wine Cork Pull Tester Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

Wine Cork Pull Tester About

Product Description

Wine Cork Pull Tester is a high-precision testing instrument designed to accurately measure the pull force required to remove corks from wine bottles. Built with a robust heavy-duty metal frame, this tester delivers reliable and repeatable test results for wineries, cork manufacturers, packaging laboratories, beverage quality control facilities, and research institutions.

Equipped with a digital force gauge, the tester offers clear force readings in multiple units including lbf, kgf, and Newton (N). Its rapid lever-action mechanism and stable bottle fixture enable quick bottle changeovers while maintaining excellent testing consistency. The instrument also supports RS-232C, Digimatic, and analog outputs, making it ideal for data collection, quality documentation, and production monitoring.

The optional SW-1 Data Acquisition Software allows users to log, analyze, and generate reports in Microsoft Excel, making this wine cork pull tester a complete solution for professional quality assurance and laboratory testing.

Key Features

Heavy-duty metal construction for long service life

Maximum load capacity of 110 lbf (50 kgf)

2.3 inch (60 mm) stroke with rapid lever operation

Measures force in lbf, kgf, and Newton (N)

High-accuracy digital force gauge with peak value capture

Stable bottle holding fixture for repeatable testing

Push-button tare function for quick zero adjustment

Overload protection up to 200% Full Scale

Audible and visual overload indication

RS-232C, Digimatic, and analog output for data transfer

Operates on rechargeable Ni-MH batteries or AC adapter

EL backlit display for clear visibility in low-light environments

Programmable high/low setpoints with color-coded LED indicators

Multi-language operating menu

Stores up to 1,000 measurement records

Optional SW-1 software for Excel-based data acquisition and analysis

Advanced Features and Reliable Performance

The Wine Cork Pull Tester offers advanced features such as peak hold function, overload protection, and high/low set points to ensure accuracy and safety during testing. Its digital LCD with EL backlight and data memory for 1000 readings enable easy monitoring and advanced documentation. USB and RS-232 ports provide versatile data output options. This robust, silver-colored tester is ideal for both industrial and laboratory environments where precise cork strength testing is essential.

Efficient Quality Control in Cork and Wine Industries

This tester is tailored for use in wine industries, packaging QC labs, and cork manufacturing facilities, supporting standard wine bottle sizes for streamlined testing. Operated by a simple manual lever and powered via rechargeable battery or AC adapter, it offers consistent, accurate evaluations. The bench-top format and durable MS material construction ensure long-term, reliable use in quality control settings.

FAQ's of Wine Cork Pull Tester:

Q: How does the Wine Cork Pull Tester operate for cork strength testing?

A: Operation is manual lever-based. Place a standard wine bottle in the fixture, attach the cork puller, and activate the lever. The tester digitally records and displays the peak force required to extract the cork, ensuring precise measurements every time.

Q: What types of data output are available for quality analysis?

A: This device supports USB and RS-232C output, along with Digimatic and analog options. Data (up to 1000 test readings) can be quickly exported for further analysis, reporting, or quality control documentation.

Q: When should the Wine Cork Pull Tester be used in the production process?

A: It should be employed during quality assurance phases, especially after cork insertion and before product distribution. Regular testing helps wine makers and cork manufacturers ensure cork integrity and bottle sealing performance.

Q: Where is the Wine Cork Pull Tester typically installed or used?

A: Installation is on a sturdy laboratory or factory bench. This tester is suitable for quality control labs, wine packaging lines, cork manufacturing plants, and research facilities focused on wine bottle packaging.

Q: What is the specimen size and force range this tester accommodates?

A: It is designed for standard wine bottles, handling cork pull strengths from 0 to 110 lbf (0-490 N). The adjustable fixture allows fitting of most standard bottle types, making it adaptable for industry needs.

Q: What are the main benefits of using this Wine Cork Pull Tester for laboratories and manufacturers?

A: The tester ensures consistent, objective, and reproducible measurement of cork extraction forces. Features like peak hold, overload protection, and digital data memory streamline the QC process, reduce manual errors, and facilitate compliance with industry standards.
